Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007
Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007 - Image 2
Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007 - Image 3
Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007 - Image 4

Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007

SKU XS.00614 100-00341 Category Tag

Throttle Body Wiring 100-00341 Fits GM 6.0L LQ9 2003-2005 2006 2007

Features: Aftermarket Premium Quick installation, easy to operate Manufactured with high quality and durable design Description: Throttle Body Connector Cable FOR GM 6.0L LQ9 (03-07) CONNECTOR PIN ASSIGNMENT: PIN WIRE FUNCTION A 18ga YEL TAC MOTOR CONTROL – 1 B 18ga WHT TP SENSOR 2 GROUND C 18ga BR NT AC 18ga BRN MOTOR CONTROL – 2 D 18ga BLK TP SENSOR 1 GROUND E 18ga LT BLU TP SENSOR 2 POWER (5V) F 18ga PPL TP SENSOR 2 SIGNAL G 18ga DK GRN TP SENSOR 1 SIGNAL H 18ga GRY TP SENSOR 1 POWER (5V) Package Included: 1 pc connecting cable
